Main Parameters
|
Item |
Specification |
Remark |
|
Nominal Capacity |
22000 mAh |
0.2 C discharge |
|
Minimum Capacity |
21450 mAh |
0.2 C discharge |
|
Nominal Voltage |
3.7V |
|
|
Charge Voltage |
4.2 ± 0.02V |
|
|
Charge Current |
Standard charge : 0.5C ( 11A) Rapid charge : 2.0 C (44A) |
|
|
Charging Time |
Standard charge : 3.0 hours (Ref.) Rapid charge : 1.0 hours (Ref.) |
|
|
Max. charge current |
2.0 C ( 44A ) |
|
|
Consistent Discharge Current |
3.0C ( 6A) |
|
|
Consistent Discharge Current |
10.0 C (220A) ≤10S |
|
|
Max. Discharge Current |
20.0C (440A) ≤1S |
|
|
Cutoff Voltage |
3.0V |
|
|
Resistance |
≤ 3mΩ |
1kHz AC Method |
|
Weight (Approx.) |
425 g |
|
|
Dimensions(T.W.H.) |
Thickness:10.9±0.4mm Width: 90.0±1.5mm Length: 190±2.0mm |
|
|
Operating Temperature |
Charge: 0 ~ 45℃ Discharge : 0 ~ 45℃ |
|
|
Storage Temperature |
Short period less within one month at -10℃~35℃ |
Long period more over 1 month at 0℃~25℃ 0℃~25℃ |
Reference Models
|
Model |
C-rate |
Capacity |
Voltage |
WT (g) |
3S (mm) - Wt(g) |
4S (mm) - WT(g) |
6S (mm) - WT(g) |
|||
|
703866-1400mAh |
120C |
1400 |
4.2V |
34 |
22*39*76 |
127 |
29*39*76 |
165 |
43*39*76 |
234 |
|
803562-1500mAh |
140C |
1500 |
4.2V |
36 |
25*36*72 |
130 |
33*36*72 |
168 |
49*36*73 |
242 |
|
723866-1550mAh |
120C |
1550 |
4.2V |
39 |
22*39*76 |
138 |
29*39*76 |
180 |
43*39*76 |
262 |
|
853866-1800mAh |
140C |
1800 |
4.2V |
45 |
26*39*76 |
160 |
35*39*76 |
204 |
52*39*76 |
296 |
|
903866-2000mAh |
140C |
2000 |
4.2V |
48 |
28*39*76 |
170 |
37*39*76 |
212 |
55*39*76 |
318 |
|
626888-3600mAh |
120C |
3600 |
4.2V |
82 |
20*69*98 |
272 |
27*69*98 |
361 |
39*69*98 |
527 |
|
703866-1600mAh |
100C |
1600 |
4.35V |
36 |
22*39*76 |
133 |
29*39*76 |
173 |
43*39*76 |
246 |
|
626888-3800mAh |
100C |
3600 |
4.35V |
82 |
20*69*98 |
272 |
27*69*98 |
361 |
39*69*98 |
527 |
|
6448145-4500mAh |
80C |
4500 |
4.2V |
98 |
20*49*157 |
372 |
27*49*157 |
475 |
39*49*157 |
478 |
|
7148145-5000mAh |
80C |
5000 |
4.2V |
110 |
22*49*157 |
400 |
29*49*157 |
482 |
43*49*157 |
711 |
|
7748145-5500mAh |
60C |
5500 |
4.2V |
120 |
24*49*157 |
433 |
30*49*157 |
545 |
48*49*157 |
767 |
|
8548145-6000mAh |
40C |
6000 |
4.2V |
136 |
26*49*157 |
469 |
35*49*157 |
608 |
52*49*157 |
884 |
|
9048145-6500mAh |
40C |
6500 |
4.2V |
144 |
28*49*157 |
502 |
37*49*157 |
646 |
55*49*157 |
934 |
|
11543128-6500mAh |
40C |
6500 |
4.2V |
145 |
34*44*138 |
505 |
46*44*138 |
650 |
68*44*138 |
940 |
|
1048145-7000mAh |
40C |
7000 |
4.2V |
156 |
31*49*157 |
538 |
41*49*157 |
694 |
61*49*157 |
1006 |
|
1248145-8000mAh |
30C |
8000 |
4.2V |
190 |
37*49*157 |
640 |
49*49*157 |
830 |
73*49*157 |
1210 |
|
1448145-10000mAh |
30C |
10000 |
4.2V |
220 |
43*49*157 |
730 |
57*49*157 |
950 |
85*49*157 |
1390 |
|
753866-2500mAh |
20C |
2500 |
4.4V |
39 |
23*39*76 |
138 |
31*39*76 |
180 |
46*39*76 |
262 |
|
1210205-22000mAh |
20C |
22000 |
4.2V |
410 |
36*101*215 |
1300 |
48*101*215 |
1710 |
72*101*215 |
2530 |
|
1210205-25000mAh |
10C |
25000 |
4.35V |
420 |
36*101*215 |
1330 |
48*101*215 |
1750 |
72*101*215 |
2590 |
If you need any other high C-rate Lipo cells, please contact us freely, we provide OEM ODM services!
Application
Our 22000mAh LiPo battery powers mission-critical systems across industries:
*Drones: Agricultural spraying, cargo delivery, military surveillance.
*Electric Vehicles: Racing cars, AGVs, RVs.
*Aerospace: UAVs, fixed-wing drones, FPV aircraft.
*Industrial Equipment: Medical electronics, deep-sea diving tools, railway systems.
Case Study: A leading drone manufacturer achieved 30% longer flight times using our battery for crop-spraying drones, reducing downtime in large-scale farming operations.
Strict control of product quality, so that you can rest assured
full capacity
Using excellent cell capacity,low internal resistance and stable voltage.
Stable performance
Long cycle life, wide operating temperature range andstable discharge voltage.
Rest assured
High protection, built-in protection board.
Fast charging ability is outstanding
The battery has low internal resistance, high discharge rate and strong pulse ability.
* Use high hardness custom sponge to strengthen the battery
* 5 layersof dangerous goods export corrugated carton
* Positive and negative paste insulation tape
* We will label test data on each cell before delivery
* lf customer have requirement, we can provide Wooden Packing forshipping.
Service support
Good consistency
Test shipping
.
Fast delivery
FAQ
Q1: What's the warranty period?
A1: As for our high C-rate Lipo cells, we usually provide 12+2 months warranty after the cells produced and sent out to you. If you need special warranty, please contact us to communicate.
Q2: What is the cycle life of the cells ?
A2: This is high C-rate battery cells, the cycles life is over 500 times @ 80% SOH, as for our models, the cycles life is from 600-1000 times @70%SOH depend on different models.
Q3: How long does this battery last in a drone?
A3: With 22000mAh capacity, drones like the DJI Agras T30 achieve up to 45 minutes of flight time per charge.
Q4: The battery cells belong to DG products and how can we ship it ?
A4: Yes, the battery cells belong to DG, If the power energy is below 20Wh, it can send without DG packaging certificates, if the energy power over 20Wh, we will provide DG packaging certificates, UN38.3, MSDS, the goods still can be send out to you successfully.
